A portable vertical platform lift designed to provide safe wheelchair access where permanent lift installations are impractical, costly, or not permitted.
The Mobilift CX is highly suitable for providing access to stages, elevated platforms, and historic buildings where structural modifications are not possible. Its design allows it to be positioned quickly and securely when needed, and stored away when not in use.
Featuring a manual operation system, it requires no power source, meaning it is always ready to use and can be deployed in any environment, indoor or outdoor, regardless of power availability. The simple hand-crank mechanism is designed to be low-effort, requiring just 5 lbs of force to lift a 300 lbs load.
Portability is a key focus: the lift is equipped with non-marring wheels and can be easily rolled across various surfaces by a single person. It is an ideal solution for schools, community halls, event venues, and temporary installations.
| Specification | Details |
|---|---|
| Typical lifting time | 20 seconds to maximum height of 60" |
| Maximum lifting height | 60" (1.52 m) |
| Crank force required | 2.2 kg crank force to lift 68 kg; 5 kg crank force to lift 136 kg |
| Capacity | 600 lbs (275 kg) |
| Lift weight | 265 lbs (120 kg) |
| Lift height | 66" (1.67 m) |
| Lift width | 37.5" (0.95 m) |
| Length | 72" (1.83 m) |
| Platform size | 34" × 56" (0.86 m × 1.42 m) |
| Platform accommodation | Accommodates a large wheelchair or scooter |
| Bridge ramp size | 20" L × 32" W (0.51 m × 0.81 m) |
The Mobilift CX comes with a comprehensive warranty covering parts and manufacturing defects. Our dedicated support team provides assistance with:
Expert assistance for initial setup and positioning.
Regular care instructions to ensure long-term reliability.
Dedicated technical support for any operational queries.
Engineered for strength and reliability, the Mobilift CX can safely lift up to 272 kg. This generous capacity makes it suitable for most manual and powered wheelchairs, delivering dependable accessibility without the need for permanent building modifications.
Not at all. The Mobilift CX is engineered with a geared lifting mechanism that requires only 5 kg of crank force to raise or lower the platform. This low operating effort makes it comfortable for carers, staff, or attendants to use while still safely lifting loads of up to 272 kg.
The Mobilift CX provides a maximum lifting height of 1.5 metres, making it ideal for overcoming stages, platforms, raised entrances, and other level changes where permanent access solutions aren’t practical. Its lifting range provides safe, stable, and reliable wheelchair access in a wide variety of temporary and permanent applications.
Yes. We offer nationwide delivery across Australia, making it easy to get a Mobilift CX wherever you need it. Whether you’re purchasing or hiring, we can arrange delivery to businesses, schools, event venues, councils, and other locations across the country.
No. The Mobilift CX is completely manually operated and requires no electricity, batteries, or external power source. This makes it a reliable and versatile accessibility solution that can be used virtually anywhere, including outdoor events, remote locations, and buildings where power isn’t readily available
Yes. The Mobilift CX is designed to be portable, allowing it to be easily relocated between sites as needed. This makes it an ideal solution for organisations that require temporary wheelchair access across multiple venues, events, or facilities without the need for permanent installation.
Yes. We offer flexible short-term and long-term rental options to suit a wide range of accessibility needs. Whether you need the Mobilift CX for a single event, a temporary building closure, or an extended project, we can provide a rental solution that fits your requirements.
Yes. We can provide setup guidance and operator training to ensure your team can use the Mobilift CX safely and confidently. Whether you’re purchasing or hiring the lift, we’ll make sure you understand the correct operation, safety procedures, and best practices before use
